Windrowers

Description

Case IH Windrowers allow you to get to the field faster and muscle through the tough spots, all without sacrificing harvest quality or operator comfort. Transport speeds up to 30 mph and cutting speeds up to 20 mph together with simplified operations and innovations such as Field Cruise and the Triple Windrower Attachment bring peak efficiency to your operation.

CURRENT MODELS:

  • WD1505- The 4-cylinder, Tier 4 B/Final compliant WD1505 delivers 150 horsepower to provide the power and efficiency you need.
  • WD2105- The 6-cylinder, Tier 4 B/Final compliant WD2105 delivers 210 horsepower providing you the power you need to muscle through tough spots.
  • WD2505- The 6-cylinder, Tier 4 B/Final compliant WD2505 delivers 250 horsepower providing maximum performance to handle heavy crops, wet conditions and hillsides with ease.
  • ENGINES: Efficient, Powerful, Clean Engines Emission-compliant, biodiesel-approved engines provide muscle to handle heavy loads, wet conditions and hillsides without slowdown.

  • Efficient Power- The WD5 series windrowers offer engines with Case IH Efficient Power technology. Windrower field tests have demonstrated a minimum of 10 percent operating cost advantage compared to similar windrowers. The 4-cylinder WD1505 and 6-cylinder WD2105 and WD2505 deliver 150, 210 and 250 horsepower, respectively.
  • Windrower engines feature turbocharger, air-to-air intercooling and computer-aided-design parent bore block with contoured outer surface for increased overall block strength and reduced noise and vibration.
  • Clean Power-
  • The windrowers are equipped with our patented Selective Catalytic Reduction (SCR) - only exhaust aftertreatment technology to meet Tier 4 B/Final emissions requirements. Because SCR does its work outside the engine, the engine can be tuned to operate at its peak power and fuel efficiency.

    ECO Power Mode The machine continuously monitors engine load and maintains the lowest engine speed to maintain the desired ground speed. When heavier crop is encountered, the engine speed increases to what is needed. If the crop is so heavy that disc speed drops, ground speed will be temporarily lowered.

    Power Cruise Mode- In this mode, the engine load is kept consistent by varying the ground speed. In heavy crop, the speed is decreased; in light crop it is increased.

    Headland Feature- This mode allows the operator to negotiate headlands more easily. A single button on the multi-function handle can be set to slow the machine and raise the head. Once the operator gets lined up for the next pass, another press of the same button will lower the head and return the machine to the preset speed. The headland sequence can also control a merger attachment (if equipped). This feature can run simultaneously with either ECO Power or Power Cruise modes.

    OPERATOR ENVIRONMENT: The Ultimate in Cab Comfort and Function

    Cab Comfort-

  • Tuned cab suspension provides better fore/aft stabilization for those long haying days
  • Suspended cab and air bag rear-axle suspension results in a smoother ride
  • Larger, easy-entry steps, leather ventilated seat, and additional window tinting for a cool and comfortable workday
  • Optional Bluetooth® radio lets you listen to your favorite music or talk hands-free
  • Multifunction Handle-

  • The Multifunction Handle is available on all models
  • Handle features several ergonomic enhancements for increased operator productivity and comfort
  • Lighting Packages- Three different lighting packages based on operational need:

  • The standard package featuring 4 Halogen work lights in the roofline, 2 Halogen rear facing lights and 2 halogen stubble lights
  • The deluxe package featuring 4 high-output LED lights in the roofline, 2 Halogen rear facing lights and 2 stubble lights
  • The premium package featuring 4 high-output LED lights in the roofline, 2 high output LED rear facing lights and 2 high-output LED stubble lights.
  • AFS TECHNOLOGY: AFS Provides Peak Efficiency Case IH windrowers feature integrated Advanced Farming Systems (AFS) technology, including the AFS Pro 700 display, to manage autoguidance, control key machine functions including Field Cruise and monitor windrower performance.

    Integrated Guidance Option-

  • Guidance Complete – display, receiver and navigation controller; WAAS or OmniStar
  • All WD5 are autoguidance ready. Units may be ordered auto-guidance complete from the factory or completed by the dealership.
  • Faster Line Approach for More Productivity-

  • The WD5 series can approach a guidance line at speeds greater than 10 miles per hour.
  • Maximum Line Acquisition-

  • Angle improved to 90 degrees.
  • An operator needs to simply drive near the next line, press the autoguidance activate button, and then the WD5 takes over.
  • Even when the Windrower is perpendicular to a guidance line, it’s possible to activate guidance.
  • Smoother, Faster, and More Accurate Line Acquisition.-

  • WD5 models move to acquire the line almost immediately and lock on 30% faster. The WD5 sweeps to the line smoothly without abrupt or jerky auto guidance movements.
  • MAINTENANCE & UPTIME: Designed to Work Hard All Day, Day After Day

    Designed for Serviceability- The swing-out door behind the cab and lift-up side shields provide easy access to the engine and key maintenance points

  • The rotary self-cleaning radiator screen keeps air flowing without restriction to the radiator.
  • The hinged swing-out cover opens wide to allow access to the air-conditioning condenser, hydraulic oil cooler, radiator and intercooler.
  • 120-gal (454L) fuel capacity and 19-gal (71.9L) DEF capacity means you can work a day without refills.
  • Fuel fill, hydraulic reservoir and hydraulic filters are accessible from ground level.
  • Conditioning roll pressure can be adjusted with a single hand crank.
  • Windrow shields and swath boards easily adjust without tools.
